BD-Power Allison 1000 Transmission

$3,825.00

BD Power 2007.5-2010 Duramax 6.6L LMM Transmission Kits:
2007-2010 LMM Allison 1000 2wd 1064742
2007-2010 LMM Allison 1000 4wd 1064744

While the Allison is suitable for stock applications, we’ve found that it does have its limitations— particularly when flywheel horsepower exceeds 370 horsepower. That’s when the stock clutch packs can begin to slip, putting the computer in the dreaded “limp home” mode and once a clutch has slipped, the next time it will slip easier and easier.

 Highlights of our modifications:
 BD rigid aluminum heavy duty transmission pan
   • Adds 3.5qt extra oil capacity
   • Reduces case flex
   • Reduces internal oil leakage
   • Heat-dissipating fins keep temperature down
   • Magnetic drain plug
New convertor lock up valve to boost lock-up pressures
Updated lube
Updated regulator
Updated pressure release spring
20% more friction surface
High energy clutch material
Added extra frictions
Modified power pistons
Modified hydraulics
New return springs
Increased main line oil pressure
Modified separator plate for short crisp shifts
New A & B trim valves, springs and solenoids
 WARRANTY: 36-month / 150,000 mile limited exchange warranty on non-competitive, racing or sled-pulling applications. Some conditions apply - See warranty statement for further details. Options:
BD Triple Torque Force Converters
   • One-piece billet cover prevents warping
   • Trapezoid teeth hold the clutches
   • Three times the holding power over stock units
   • Less friction wear and no rattling
   • BD’s own designed cast stator
BD FleX-Plate
   • Meets SFI 29.3

CLUTCH

STOCK

BD

C1

6

8

C2

6

7

C3

4

6

C4

5

6

C5

6

7
